TP-Link RE305 AC1200 Dual Band Wifi Range Extender/ AP, 1x10/ 100 RJ45, power schedule

Bezdrôtový Extender RE305

• Oživí mŕtve zóny vo Wi-Fi sieti vďaka silnému rozšíreniu s kombinovanou rýchlosťou prenosu dát až 1,2Gbit / s
• Pracuje vobou pásmach 2,4GHz (300Mbit / s) i 5GHz (867Mbit / s) a zaistí stabilnejšie používanie bezdrôtovej siete
• Inteligentné kontrolka signálu pomáha vďaka indikáciu sily signálu nájsť pre extender najlepšie umiestnenie, aby pokrytie Wi-Fi signálom bolo optimálne
• Pracuje s akýmkoľvek Wi-Fi routerom alebo bezdrôtovým prístupovým bodom

HARDWARE FEATURES

• Plug Type

EÚ, UK, US

• Standards and Protocols

IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b

• Interface

1 * 10 / 100M Ethernet Port (RJ45)

• Buttons

WPS Button, Reset Button

• Power Consumption

7.3W (max power consumption)

• Antenna

2 * external

• Dimensions (W x D x H)

80 * 78 * 77mm

WIRELESS FEATURES

• Frequency

2.4GHz & 5GHz (11ac)

• Signal Rate

5GHz: Up to 867Mbps
2.4GHz: Up to 300Mpbs

• Reception Sensitivity
• 5GHz:

11a 6Mbps: -91dBm @ 10% PER
11a 54Mbps: -74dBm @ 10% PER
11ac HT20 mcs8: -68dBm @ 10% PER
11ac HT40 mcs9: -63dBm @ 10% PER
11ac HT80 mcs9: -59dBm @ 10% PER

• 2.4GHz

11g 54M: -79dBm @ 10% PER
11n HT20 mcs7: -77dBm @ 10% PER
11n HT40 mcs7: -74dBm @ 10% PER

• Wireless Modes

Range Extender / Access Point
wireless Statistic
Concurrent Mode boost both 2.4G / 5G Wi-Fi band

• Wireless Functions

wireless Statistic
Concurrent Mode boost both 2.4G / 5G Wi-Fi band
Access Control
LED Control
Domain Login Function

• Wireless Security

64/128-bit WEP
WPA-PSK / WPA2-PSK

• Transmission Power

<17dB (2.4GHz)
<17dB (5GHz)

• OTHERS
• Certification

CE, FCC, RoHS

• Package Contents

AC1200 Wi-Fi Range Extender RE305
Quick Installation Guide

• Box Dimensions (W X D X H)

156.5 * 101.5 * 95mm

• System Requirements

Microsoft® Windows® 98SE, NT, 2000, XP, Vista alebo Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.

• Environment

Operating Temperature: 0 ° C ~ 40 ° C
Storage Temperature: -40 ° C ~ 70 ° C
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
